Glass & Silica — Clear Float Glass 4 mm & Glass-Grade Silica Sand
Clear float glass 4 mm (2140 × 3300 mm, EN 572) and Egyptian glass- and foundry-grade silica sand (SiO₂ 98–99 %) for export. ISO 9001 supply, CoA per lot before B/L, containerised or bulk from Damietta / Alexandria / El Dekheila / Ain Sokhna. Quote in 24 hours.
1 product ready for export
Glass & silica — from Zafarana sand to finished float glass
Egypt's glass industry is built on its silica: the white quartz sands of Zafarana on the Gulf of Suez and the Sinai deposits run to 98–99 % SiO₂ with low iron, which is what float and container glass lines require. Egypt Globe Group supplies both ends of that chain — clear float glass 4 mm in 2140 × 3300 mm jumbo sheets for construction glazing, and the silica sand behind it, in glass grade SiO₂ 99 %, standard 98 %, foundry grade AFS 50–55 and 200-mesh silica flour for oilwell cementing and paints.
For a glass melter, iron is the controlling impurity — a few hundredths of a percent of Fe₂O₃ moves a clear melt to green. For a foundry, it is clay content and grain distribution (AFS number) that decide mould strength and casting surface. For a glazing contractor, it is thickness tolerance and optical defects. Regional suppliers often ship on a typical analysis rather than a lot analysis. EGG's QA division samples every sand lot at the washing plant and port and every glass lot at the packing line, and issues a Certificate of Analysis or inspection report before the Bill of Lading. Out-of-spec lots are rejected at the loading port.
Technical specification
Clear float glass 4 mm — physical properties
| Parameter | Specification | Test method | Standard |
|---|---|---|---|
| Nominal thickness | 4 mm; tolerance ± 0.2 mm | Micrometer, EN 572-2 | EN 572-1 / EN 572-2 |
| Sheet size | 2140 × 3300 mm (jumbo); cut sizes on request | Tape, EN 572-8 | EN 572-8 |
| Visible light transmittance | ≈ 89 % | Spectrophotometer, EN 410 | EN 410 |
| Density | 2,500 kg/m³ | EN 572-1 | EN 572-1 |
| Optical and visual defects | Per EN 572-2 quality class for float | Visual inspection against light | EN 572-2 |
| Edge | Clean-cut, stacked on A-frame or end-cap racks | Visual | — |
| Origin | Egypt / China (declared per contract) | Certificate of Origin | — |
Silica sand — chemical analysis and grain size by grade
| Parameter | Glass grade (egg-sil-004) | Standard grade (egg-sil-001) | Foundry grade (egg-sil-003) | Test method |
|---|---|---|---|---|
| SiO₂ | ≥ 99 % | ≥ 98 % | ≥ 97 % | XRF / gravimetric |
| Fe₂O₃ | ≤ 0.03 % | ≤ 0.10 % | ≤ 0.30 % | XRF |
| Al₂O₃ | ≤ 0.5 % | ≤ 1.0 % | ≤ 1.0 % | XRF |
| Loss on ignition | ≤ 0.3 % | ≤ 0.5 % | ≤ 0.5 % | Gravimetric |
| Grain size | 0.1–0.6 mm, washed and classified | 0.1–1.0 mm | AFS 50–55, low clay (≤ 0.5 %) | Sieve, ISO 3310 / AFS 1105 |
| Moisture | ≤ 5 % (washed) / ≤ 0.5 % (dried) | ≤ 5 % | ≤ 0.5 % dried | Oven drying |
| Origin | Egypt, Zafarana | Egypt, Sinai | Egypt, Delta region | Certificate of Origin |
Logistical & QA parameters
| Parameter | Detail |
|---|---|
| MOQ — containerised (FCL) | Float glass 10 MT (contracts to 500 MT); silica sand 100 MT |
| MOQ — break-bulk vessel | Glass-grade silica 500 MT (contracts to 50,000 MT); foundry grade 200 MT (to 20,000 MT) |
| Packing | Float glass: end-cap / A-frame crates in 20' containers; silica: bulk vessel · 1 MT FIBC · 25 kg PP bags |
| Loading ports | Damietta (EGDAM), Alexandria (EGALY), El Dekheila (EGEDK), Ain Sokhna (EGSOK) |
| Incoterms | Float glass CIF / DAP; silica FOB / CFR / CIF |
| Lead time | 2–4 weeks |
| Independent inspection protocol | SGS / TÜV Austria / Intertek: glass — packing and breakage inspection, thickness and defect check per EN 572-2; sand — increment sampling, witness XRF and sieve analysis, draft survey on bulk |
| Internal QA gate | Per-lot CoA (SiO₂, Fe₂O₃, Al₂O₃, LOI, PSD, moisture) or glass inspection report issued by the port laboratory before B/L; out-of-spec lots rejected at the loading port |
| HS code | 7005.29 float glass · 2505.10 silica sand · 2505.90 silica flour |
QA verification chain
| Gate | Control | Evidence | Who · frequency |
|---|---|---|---|
| Deposit / plant | Sand: bench sampling and iron check; glass: float-line thickness and optical scan | Bench XRF sheet, line QC record | EGG QA field team / producer QC · per lot |
| Processing | Washing, attrition scrubbing, magnetic separation, classification; glass cutting and stacking | Process log, PSD record | Producer QC under EGG supervision · per shift |
| Port laboratory | XRF chemistry, LOI, sieve / AFS analysis, moisture; glass thickness and defect inspection | CoA or inspection report before B/L | EGG port laboratory · every lot |
| Independent inspection | Sampling, witness test, container stuffing or draft survey | SGS / TÜV Austria / Intertek certificate | Third party · per shipment |
| Destination acceptance | Buyer melt-shop or foundry laboratory re-test against CoA | Buyer report reconciled with CoA | Buyer · on arrival |
Applications & markets
- Float, container and sheet glass batch; ceramics bodies and glazes: glass & ceramics.
- Foundry moulding sand and silica flour for well cementing: steel & metals, oil & gas.
- Construction glazing, façades and partitions: construction, stone & architecture.
- Related minerals: silica sand catalogue, feldspar, dolomite; market intelligence: mining companies in Egypt.
Standards & documentation
- EN 572-1 / -2 / -8 (basic soda-lime glass), EN 410 (optical), ISO 3310 and AFS 1105 (grain size), XRF per EN 196-2 — referenced on every CoA; ISO 9001 supplier systems.
- Documentation · Inspection · Packing · Quality & compliance · HS codes.
Request a quote
State product (float glass size and quantity, or silica grade, SiO₂ / Fe₂O₃ limits and grain size), destination and Incoterm; a written offer with CoA format and lead time is returned within 24 hours. Request a quote or request a quote directly.
