Egyptian Aggregates — Crushed Granite 20 mm & Dolomite 10 mm Chips
Egyptian construction aggregates for export: crushed granite 20 mm (Aswan / Eastern Desert) for concrete and road base, dolomite 10 mm chips for asphalt, glass and refractory. EN 12620 / EN 13043 / BS 812, gradation report and ACV per lot before B/L, bulk FOB Damietta / Alexandria / Ain Sokhna.
2 products ready for export
Egyptian aggregates — graded, tested and released per lot
Egypt's hard-rock quarries — the Aswan and Eastern Desert granites and the Western Desert dolomites — produce crushed aggregate with the particle strength and low absorption that structural concrete, asphalt and industrial batch require, at a freight distance that makes Egyptian rock competitive into the Gulf, East Africa and the eastern Mediterranean where local sources are weak or absent. Egypt Globe Group supplies two lines: crushed granite aggregate 20 mm for concrete production and road base, and dolomite aggregate 10 mm chips for asphalt surfacing, glass batch and refractory.
Aggregate quality is a grading and soundness question. A concrete producer who receives a 10/20 fraction with 15 % oversize or 8 % fines has to redesign the mix on site; an asphalt plant that receives soft or flaky chips fails its polished-stone and Los Angeles tests. Many regional quarries ship on a visual check. EGG's QA division runs a sieve analysis, flakiness index, aggregate crushing value and water absorption on every lot at the port laboratory and issues a gradation report and Certificate of Analysis before the Bill of Lading. Lots outside the contractual grading envelope are rejected at the loading port.
Technical specification
Crushed granite aggregate 20 mm — physical properties
| Parameter | Specification | Test method | Standard |
|---|---|---|---|
| Grading | 10/20 mm (Gc 85/20) | EN 933-1 | EN 12620 / ASTM C33 size 7 |
| Flakiness index | ≤ 25 | EN 933-3 | EN 12620 |
| Los Angeles coefficient | ≤ 30 (LA30) | EN 1097-2 | EN 12620 |
| Aggregate crushing value (ACV) | ≤ 25 % | BS 812-110 | BS 882 / BS 812 |
| Particle density (oven-dry) | ≥ 2.60 Mg/m³ | EN 1097-6 | EN 12620 |
| Water absorption | ≤ 1.0 % | EN 1097-6 | EN 12620 |
| Magnesium sulphate soundness | ≤ 18 % | EN 1367-2 | EN 12620 |
| Origin | Egypt (Aswan / Eastern Desert) | Certificate of Origin | — |
Crushed granite aggregate 20 mm — chemical analysis
| Parameter | Limit | Test method | QA sampling |
|---|---|---|---|
| Water-soluble chloride | ≤ 0.01 % | EN 1744-1 | Per lot |
| Acid-soluble sulphate (SO₃) | ≤ 0.2 % | EN 1744-1 | Per lot |
| Alkali-silica reactivity | Non-reactive / low-reactivity petrographic classification | EN 12407 petrography; ASTM C1260 on request | Per source / per contract |
| Clay lumps and friable particles | ≤ 1 % | EN 933-9 / ASTM C142 | Per lot |
Dolomite aggregate 10 mm chips — physical & chemical properties
| Parameter | Specification | Test method | Standard |
|---|---|---|---|
| Grading | 4/10 mm chips | EN 933-1 | EN 13043 / EN 12620 |
| Flakiness index | ≤ 20 | EN 933-3 | EN 13043 |
| Los Angeles coefficient | ≤ 25 | EN 1097-2 | EN 13043 |
| Particle density | ≥ 2.70 Mg/m³ | EN 1097-6 | — |
| Water absorption | ≤ 1.0 % | EN 1097-6 | — |
| Chemistry (glass / refractory use) | MgO ≥ 18 %, CaO ≥ 30 %, SiO₂ ≤ 2 %, Fe₂O₃ ≤ 0.5 % on Egyptian dolomite — see dolomite lump | XRF / ASTM C25 | Per lot |
| Origin | Egypt | Certificate of Origin | — |
Logistical & QA parameters
| Parameter | Detail |
|---|---|
| MOQ — containerised (FCL) | 500 MT dolomite chips; 1,000 MT crushed granite |
| MOQ — break-bulk vessel | 1,000 MT granite (contracts to 200,000 MT); dolomite chips to 50,000 MT |
| Packing | Bulk vessel · 1 MT FIBC jumbo bags · 50 kg PP woven bags |
| Loading ports | Damietta (EGDAM), Alexandria (EGALY), El Dekheila (EGEDK), Ain Sokhna (EGSOK) |
| Incoterms | FOB (dolomite); FOB / CFR (granite); CIF on request |
| Lead time | 2–4 weeks |
| Independent inspection protocol | SGS / TÜV Austria / Intertek / Bureau Veritas: sampling per EN 932-1, witness sieve analysis and ACV / LA test, draft survey on bulk cargo |
| Internal QA gate | Per-lot gradation report and CoA (grading, flakiness, LA / ACV, absorption, chloride) from the port laboratory before B/L; out-of-spec lots rejected at the loading port |
| HS code | 2517.10 crushed granite · 2518.10 dolomite |
QA verification chain
| Gate | Control | Evidence | Who · frequency |
|---|---|---|---|
| Quarry face | Rock-type selection, weathering and vein exclusion, petrographic classification | Source petrography (EN 12407), bench record | EGG QA field team · per source / per lot |
| Crushing and screening | Crusher setting, screen deck calibration, washing where specified | Screen check, process log | Producer QC under EGG supervision · per shift |
| Port laboratory | Sieve analysis, flakiness, LA / ACV, density and absorption, chloride and sulphate | Gradation report + CoA before B/L | EGG port laboratory · every lot |
| Independent inspection | Sampling per EN 932-1, witness test, draft survey | SGS / TÜV Austria / Intertek / Bureau Veritas certificate | Third party · per vessel |
| Destination acceptance | Buyer laboratory re-test against CoA | Buyer report reconciled with CoA | Buyer · on arrival |
Applications & markets
- Structural concrete, precast, road base and asphalt surfacing: construction.
- Dolomite for glass batch and refractory: glass & ceramics, steel & metals.
- Related: dolomite mineral grades, Egyptian cement, mining companies in Egypt.
Standards & documentation
- EN 12620 (aggregates for concrete), EN 13043 (aggregates for bituminous mixtures), EN 933 / EN 1097 / EN 1744 test series, BS 812-110 (ACV), ASTM C33 — referenced on every CoA; ISO 9001 supplier systems.
- Documentation · Inspection · Loading ports · Quality & compliance · HS codes.
Request a quote
State rock type, fraction, quantity, destination and Incoterm; a written offer with grading envelope, CoA format and lead time is returned within 24 hours. Request a quote or request a quote directly.
